GE DINAMAP ProCare
120 Monitor, NIBP, Heart Rate & Printer |
|
Market-Leading Technologies: Designed specifically for health care
professionals who require hospital-grade quality in non-hospital
settings, the DINAMAP ProCare Series offers proven world-class
technology in every parameter. With the DINAMAP ProCare Series, you
can take BP measurements that are fast, accurate and comfortable.
Get reliable temperature -readings in seconds. And get oxygen
saturation readings with your choice of two leading-edge SpO2
technologies. Depending on your needs of data storage, you can now
choose between the printer or printerless version of the ProCare.
Which means you spend less time checking vitals and more time on
actual patient care.
User-Friendly
Design: Its lightweight at 2,5 Kg, and its large red numbers
ensure a clear bright display that is visible from around the room.
Not only that, the DINAMAP ProCare is easy to carry or wheel from
place to place or even mount on a wall as needed. Best of all,
you'll find it simple to operate, with no extensive training
required. Don’t hesitate to use the help cards, which are underneath
the monitor in case of doubt!
DINAMAP NIBP:
With more than 25 years and over 350,000 devices, DINAMAP has earned a
reputation as the gold standard in non-invasive blood pressure
measurement. And the DINAMAP ProCare Series once again proves why.
With its unique patented algorithm and artifact rejection system,
the DINAMAP ProCare ensures exceptionally accurate BP readings even
in hypertensive and hypotensive cases regardless of patient
movement. This Dinamap algorithm is adapted for every typology and
every category of patients from the neonates to the adult.
Alaris
Turbo*Temp™: An electronic thermometry system by Alaris Medical
Systems, Turbo*Temp is not only extremely accurate, but also very
fast. In fact, oral (or rectal) predictive temperatures are provided
in approximately 7 seconds, saving health care professionals
valuable time. This temperature can also be used with the monitoring
mode for axillary’s monitoring use for example.
SpO2 Accuracy
even with motions and low perfusion: Nellcor OxiMax™ technology.
Use SatSeconds™ technique to prevent you and your patients from the
alarms nuisance by controlling the time that the SpO2 level may fall
outside the alarm. Test also the low perfusion mode to be more
accurate in difficult situations.
Connectivity:
ProCare has now the ability to transfer its datas via its RS232.
Connect the monitor to your laptop (need a software) or to the Chant
server in order to collect the datas (research, HL7 connection…).
ProCare can also been connected either to an Obstetrical Corometrics
monitor or to an ApexPro GE telemetry V2.
Built to
Last: As with all DINAMAP monitors, the ProCare has been
engineered to provide years of trouble-free service. In addition to
incorporating the highest-quality materials for "hospital grade"
durability, the monitors are designed to be low maintenance and easy
to repair.
| Features |
ProCare 120 |
ProCare220 |
ProCare320 |
ProCare420 |
| DINAMAP NIBP |
Yes |
Yes |
Yes |
Yes |
| Pulse Rate |
Yes |
Yes |
Yes |
Yes |
| IVAC® Turbo•Temp™ |
|
Yes |
|
Yes |
| Nellcor OxiMax™
SpO2 |
|
|
Yes |
Yes |
| Trends |
Yes |
Yes |
Yes |
Yes |
| Printer |
Yes |
Yes |
Yes |
Yes |
| RS232 |
Yes |
Yes |
Yes |
Yes |
-
Dimensions:
9.7”x10”x5.3” (HxWxD)
-
Weight:
5.68 lb
-
Battery:
6 volt, 3.3 amp-hours
-
Minimum
operation time: 5 hrs (5 min cycle with adult cuff at 25°C, SpO2
active at 60 bpm, Temp in monitor mode) from full charge.
-
Time for
full recharge: Approx. 5 hrs from full discharge when the
Monitor is switched off and 8 hrs when the Monitor is switched
on.
-
DINAMAP
NIBP (ProCare 120, 220,
320, and 420)
-
Blood
Pressure Accuracy Meets or exceeds ANSI/AAMI standard SP-10
-
Patient
category: Adult or neonates mode
-
Cuff
Pressure Range: 10 to 290 mmHg (adult/ped); 10 to 140 mmHg
(neonate)
-
Target cuff
inflation range: between 100-250mm Hg (adults); 100-140 mm Hg
(neonate) per 5mm Hg step
-
Overpressure
Cutoff: 330 mmHg (adult/ped); 165 mmHg (neonate)
-
Pulse Rate
Range: 30 to 200 beats/min (adult/ped); 30 to 220 beats/min
(neonate)
-
Pulse Rate
Accuracy: ± 3.5%
-
Mode
settings: Manual, auto or stat mode
-
Auto mode:
Stat, 1, 2, 3, 4, 5, 10, 15, 20, 30, 60, 90, 120 min
-
IVAC®
Turbo•Temp™Temperature
(ProCare 220 & ProCare 420)
-
Scale:
°Fahrenheit (F); °Celsius (C)
-
Range:
Predictive mode Max: 41.1° C; 106.0° F; Min: 35.6° C; 96.0° F
-
Monitor mode
Max: 41.1° C; 106.0° F; Min: 26.7° C; 80.0° F
-
Accuracy:
Monitor mode accuracy ± 0.1° C; ± 0.2° F
-
Nellcor
OxiMax™
SpO2 (ProCare 320 &
ProCare 420)
-
Measurement
Range: SpO2 1 to 100%
-
Pulse Rate
20 to 250 beats/min
-
SpO2 signs:
SpO2 % value and SpO2 pulse indicator (red LED bar flashes)
-
Accuracy and
Motion Tolerance
-
Saturation
Without Motion: Adults 70 to 100% ±2 digits; Neonate 70 to 100%
±3 digits
-
Saturation
With Motion: Adults/Neo 70 to 100% ±3 digits Low Perfusion 70 to
100% ±2 digits
-
Pulse Rate
Range Without Motion: 20 to 250 beats/min ±3 digits
-
Pulse Rate
Range With Motion: normal physiologic range 55 to 125 beats/min
±5 digits Low Perfusion 20 to 250 beats/min ±3 digits
-
Alarms
-
Audible
Indicator Pitch changes continuously with saturation: volume
from 0 to 9
-
Sensor
Connect/Disconnect from patient detection within 15 s Sensor
Connect/Disconnect from monitor detection within 5 s
-
Loss of
Pulse Monitor will detect loss of pulse from patient and enter
no signal state within 10 s
-
History
-
Storage: 25
entries
-
When full,
the oldest entry is removed so the most recent entry can be
stored. Entries are automatically removed when they become older
than 24 hours
-
Entries can
be Systolic, Diastolic, MAP, Pulse Rate, SpO2, Temperature
values
-
Alarms
-
An alarm can
generate an audible indication, visual indication, alarm message
code, and electronic record in the history. The audible
indicator is based on two sounds depending on the priority of
the alarm (medium or high) ProCare provides 3 categories of
alarms:
-
Patient-related: Limit and Parameter status alarms
-
System-related: Printer, battery and memory alarms
-
System
failures
-
Alarm
suspension: 2 min
-
Volume
adjustment from 1 to 10
-
Alarm signs:
Single silence button and silence icon
-
Printer
(ProCare 120, 220, 320, and 420)
|
|
